RTS Series / Servo Drives & Motors
Very compact, they can be mounted on single Europe 3U rack or panel mounted
Different power supply possibilities: battery, single-phase or three-phase input
Numerous models available up to 6.5 kW (8.7 hp)
Control by U-RI or tachometer
CE marked products
Product Overview
RTS Series
Well-proven servo amplifiers for DC motors.
The RTS servo amplifiers are designed for driving DC servomotors and are available in numerous ratings up to 6.5 kW (8.7 hp).
These products enable speed control of DC motors with or without tachometers.
Common Characteristics
Functions with current or speed control
U-RI type control or control by tachometer generator feedback
Differential speed or current control +/-10V
Current reduction as function of speed or temperature
-Zero torque enabling input
-Zero speed enabling input
-Reset input
Analog information of speed or torque
Relay state of servo amplifier
Power supply output -15V/0/+15V
Integrated supply and recovery of braking energy
Galvanic insulation between control and power section
Different power supply possibilities depending on the model : single-phase, three-phase, battery
Mechanical power up to 6.5 kW (8.7 hp)
Examples of applications
The RTS range provides control for the whole range of DC motors.
The RTS drive and DC motor combination is economical and extremely competitive for low-power drive systems.
For example : medical equipment, three dimensional measuring machines, electronic production, office technology...
